Huawei FusionModule500 Manual

FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
3 System Architecture
Issue 01 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
39
Item
Specification
(RJ45)
of 20 W, maximum withstand voltage of 60 V DC, and rated
current of 0.5 A.

Supports one active DO port with the output voltage of 12 V DC
and output current of 450 mA.
USB
Supports USB 2.0 and provides four USB ports for connecting
devices.
Buttons

SW: wireless network pairing button.

Default: button of restoring the default IP address.
Table 3-19 Indicators on the ECC800e main control module
Indicator
Color
Name
Status
Description
RUN
Green
Module running
status indicator
Steady on
The power supply is normal,
the program is being loaded,
or WiFi WPS is pairing.
Off
The power supply is
abnormal.
Blinking
at long
intervals
The software runs properly
(the indicator blinks at 0.5
Hz, on for 1s and then off
for 1s) or the ECC800e
registers with the NetEco
successfully.
Blinking
at short
intervals
The ECC800e does not
register with the NetEco (the
indicator blinks at 4 Hz, on
for 0.125s and then off for
0.125s).
ALM
Red
Alarm indicator
Steady on
A system failure alarm is
generated.
Off
The system is normal.
PWR
Green
Power indicator
Steady on
The power supply for the
system is normal.
Off
The power supply for the
system is abnormal.
