Huawei FusionModule800

16
After routing water pipes, secure them to the refrigerant pipes using cable ties. If the pipes are
routed downwards, not only secure the pipes but also seal the cable hole using firestop putty.
Upward drainpipe routing Downward drainpipe routing
8
Installing Cables
M5 (3 PCS)
2N•m
M3 (3 PCS)
0.6-0.8N•m
