2
Camera mounting kit on
the enclosed framework
Side sealing plate
Gas spring
cabinet electronic
clasp lock
Converged cabinet
The component layout illustrates only the positions of components. The actual component
installation positions prevail.
Space requirements for the cold and hot aisle containment
Installation Scenarios
1
Smart Module Installation Scenario
• The cabinet layout shown in the figure is for ease of description and does not provide
reference for engineering layout.
• If the site conditions do not meet the space requirements, contact Huawei technical support.
IT cabinet
