5.10.1 Mainboard
Figure 5-28 2488 V5 mainboard
1 UID indicator 2 Health status indicator
3 USB 3.0 port (INNER
USB3.0)
4 PCIe x8 slot 6
(corresponding to CPU 3)
5 PCIe x8 slot 5
(corresponding to CPU 3)
6 PCIe riser slots
(corresponding to CPU 2)
7 BMC GE port (J142) 8
Jumper (J93)
a
9 VGA connector (VGA
CONN/J169)
10 Serial port (RJ45 CONN/
J171)
