Huawei FusionServer Pro 2488 V5 - Indicators and Buttons

1 Drives 2 Built-in DVD drive or
touchable LCD
3 Slide-out label plate
(with an SN label)
- -
● 24 x 2.5" (16 x SAS/SATA + 8 x NVMe) drive
conguration
Figure 5-2 Front view
1 Drives 2 Slide-out label plate (with an
SN label)
● 25 x 2.5" SAS/SATA drive
conguration
Figure 5-3 Front view
1
Drives 2 Slide-out label plate
(with an SN label)
5.1.2 Indicators and Buttons
Positions
● 8 x 2.5" SAS/SATA drive
conguration
