11 TPM port (TPM CONN/
J55)
12 USB 3.0 port (REAR
USB3.0/J172)
13 PCIe x8 slot 3
(corresponding to CPU 1)
14 PCIe x8 slot 2
(corresponding to CPU 1)
15 PCIe x16 slot 1
(corresponding to CPU 4)
16 10GE optical port (10GE
PORT0&Port1/J140)
17 GE electrical port (GE
PORT2&Port3/J138)
18 USB 3.0 port (FRONT
USB3.0/J190)
b
19 Right mounting ear
connector (J131)
20 SATA DVD drive connector
(J189)
21 PCIe x16 slot 7
(corresponding to CPU 1)
22 LCD connector (LCD
CONN/J87)
23 VGA connector (J185) 24 Fan port 4 (FAN4/J102)
25 Fan port 3 (FAN3/J103) 26 Fan port 2 (FAN2/J104)
27 Fan port 1 (FAN1/J105) 28 Drive backplane signal
connector (HDD BP/J133)
29 System battery (U4042) 30 PCIe x16 slot 9
(corresponding to CPU 3)
31 PCIe x8 slot 8
(corresponding to CPU 3)
32 Left mounting ear
connector (LEFT EAR
CONN BOARD/J115)
33 Drive backplane power
connector (BP PWR/J128)
34 PSU backplane connectors
(J209/J210/J208)
35
VROC key port (J144)
c
- -
a: The BMC_SER_MANUAL pin is used for changing the connection direction of
the physical serial port. The CLEAR_BMC_PW pin is used for restoring default
iBMC settings.
b: The built-in USB 3.0 port can be connected to the front USB 3.0 port through
a USB cable. It cannot be used directly.
c: The port is reserved.
5.10.2 Drive Backplane
● 8 x 2.5" SAS/SATA drive backplane
