Sensor Description Component
CPU N DDR VDDQ CPU DIMM voltage
CPU N DDR VDDQ2
CPU N VSA CPU VSA voltage
CPU N VCCIO CPU VCCIO voltage
PCH VPVNN PCH PVNN voltage
PCH PRIM 1V05 PCH 1.05 V voltage
SSD N Temp ES3000 V3 temperature
SAS Cable Entity presence
PS N VIN Input voltage
PwrOk Sig. Drop Voltage drop status
ACPI State ACPI status
SysFWProgress Software process and
system startup errors
SysRestart Cause of system restart
Boot Error Boot error
Watchdog2 Watchdog
Mngmnt Health Management subsystem
health status
Riser1 Card Entity presence
PCIe RAID N Temp LSI SAS3508 RAID
controller card
temperature
PCIe RAID N Temp Avago SAS3004 RAID
controller card
temperature
M2 Temp(PCIe N ) Maximum temperature
of all M.2 drives of the
RAID controller card
PCIe Status PCIe status
PwrOn TimeOut Power-on timeout
PwrCap Status Power capping status
HDD Backplane Drive backplane entity
presence
