3 Physical Structure
Figure 3-1 5288 V5 physical structure
1 I/O module 1 2 I/O module 2
3 Rear drives 4 Rear-drive backplane
5 I/O module 3 6 Chassis
7 PSUs 8 Air duct
9 Supercapacitors 10 Front-drive backplane
11 Front drives 12 Fan module brackets
