39 PSU 1 connector (J156) 40 Built-in drive low-speed
signal connector (INNER
HDD BP/J122)
41 Left mounting ear
connector (LCIA BOARD/
J161)
42
Jumper (J176)
c
43 I/O NIC connectors (IO
BOARD/J159/J158)
44 RAID controller card
connector (RAID CARD/
J48)
45 PCIe riser 2 slots
(corresponding to CPU 2/
J155)
- -
● a: "10GE optical port" corresponds to the mainboard integrated with two
10GE optical ports and two GE electrical ports. "10GE electrical port"
corresponds to the mainboard integrated with two 10GE and two GE
electrical ports.
● b: The port is reserved.
● c: COM_SW(ON) is used for changing the connection direction of the
physical serial port. BMC_RCV(ON) is used for restoring default iBMC
settings.
5.10.2 Drive Backplane
Front-Drive Backplanes
● 24 x 3.5" drive backplane
Figure 5-37 24 x 3.5" drive backplane (BOM 03024QEK)
Huawei FusionServer Pro 5288 V5 Server
Technical White Paper 5 Hardware Description
Issue 10 (2020-12-15) Copyright © Huawei Technologies Co., Ltd. 58
