9 10GE optical port (10GE
PORT1/J131) or 10GE
electrical port (10GE
PORT1/J100)
a
10
VROC key port (J130)
b
11 PCIe riser 1 slots
(corresponding to CPU 1/
J108)
12 Rear-drive backplane
power connector 2 (REAR
BP PWR2/J126)
13 NC-SI connector (NCSI
CONN/J99)
14 SATA signal connector 2
(SATA2/J71)
15 SATA signal connector 1
(SATA1/J67)
16 CPU 1 slimline connector
(CPU1 SLIMELINE/J170)
17 mini-SAS HD connector C
(MINIHD PORT C/J85)
18 mini-SAS HD connector B
(MINIHD PORT B/J84)
19 mini-SAS HD connector A
(MINIHD PORT A/J86)
20 Rear-drive backplane
power connector 1 (REAR
BP PWR1/J127)
21 USB 3.0 port (FRONT
USB3.0/J173)
22 Right mounting ear
connector (RCIC/RCIF/
RCIG BOARD/J167)
23 TPM/TCM port (TPM
CONN/J55)
24 LCD connector (LCD
CONN/J87)
25 VGA connector (VGA
BOARD/J160)
26 Fan 4 connector (2U
FAN4/J148)
27 Fan 3 connector (2U
FAN3/J145)
28 Fan 2 connector (2U
FAN2/J146)
29 Fan 1 connector (1U/2U
FAN1/J105)
30 Drive backplane connector
(HDD BP CONN/J162)
31 Built-in drive power
connector (INNER HDD
PWR/171)
32 Drive backplane power
connector 1 (HDD BP
PWR2/J128)
33 Drive backplane power
connector 2 (HDD BP
PWR2/J166)
34 Rear-drive backplane
power connector 3 (REAR
BP PWR3/J172)
35 Rear 4 x 2.5-inch drive
backplane low-speed
signal connector (REAR
4*2.5 HDD BP/J164)
36 CPU 2 slimline A
connector (CPU2
SLIMLINE A/J140)
37 CPU 2 slimline B
connector (CPU2
SLIMLINE B/J139)
38 PSU 2 connector (J157)
