5.4.2.2 Memory Subsystem Architecture
The 5288 V5 provides 24 memory slots. Each processor integrates six memory
channels, and each memory channel supports up to one DCPMM.
DCPMMs must be used with DDR4 memory modules.
Table 5-8 Memory channels
CPU Memory Channel Memory Slot
CPU 1 A (primary) DIMM000(A)
A DIMM001(G)
B (primary) DIMM010(B)
B DIMM011(H)
C (primary) DIMM020(C)
C DIMM021(I)
D (primary) DIMM030(D)
D DIMM031(J)
E (primary) DIMM040(E)
E DIMM041(K)
F (primary) DIMM050(F)
F DIMM051(L)
CPU 2 A (primary) DIMM100(A)
A DIMM101(G)
B (primary) DIMM110(B)
B DIMM111(H)
C (primary) DIMM120(C)
C DIMM121(I)
D (primary) DIMM130(D)
D DIMM131(J)
E (primary) DIMM140(E)
E DIMM141(K)
F (primary) DIMM150(F)
F DIMM151(L)
