● The mapping between the DCPMM and CPU is as follows:
– DCPMMs require Cascade Lake Gold/Platinum/Silver (4215 model) CPUs.
– Table 5-10 lists the maximum memory capacity supported by dierent
CPUs.
Table 5-10 Maximum memory capacity supported by a CPU
CPU Type Maximum Memory Capacity Supported by a CPU
(DDR4 and DCPMM Capacities)
Full-series 1 TB
M series 2 TB
L series 4.5 TB
5.4.2.5 Memory Installation Positions
A 5288 V5 supports a maximum of 12 DCPMMs. The DCPMMs must be used with
DDR4 DIMMs.
Figure 5-13 Memory slots
Figure 5-14 DCPMM and DDR4 memory conguration guidelines (1 processor)
Huawei FusionServer Pro 5288 V5 Server
Technical White Paper 5 Hardware Description
Issue 10 (2020-12-15) Copyright © Huawei Technologies Co., Ltd. 32
