Huawei HG658 V2 User Manual

9
3. On the I want to... Connect to the Internet page, selcet Agree , and click Next .
4. Select your Internet connection mode.
Refer to the following table to configure the network connection.
Scenario Connection Type
When you are unsure of the network connection you
subscribed to, you can select this mode that the device will
detect the network connection automatically.
Connect automatically
The account name and password are provided by your
Internet Service Provider (ISP).
Connect with user account
No parameter is provided by your ISP. The IP address is
automatically assigned by the ISP.
Connect without user account

Huawei HG658 V2 Specifications

General

Model	HG658 V2
Category	Gateway
Wi-Fi Standards	802.11 b/g/n
Frequency Band	2.4 GHz
Ethernet Ports	4
USB Ports	1
Wireless Speed	300 Mbps
WLAN	Yes
Number of LAN Ports	4
LAN Port Type	RJ-45
Number of FXS Ports	2
WAN Ports	1 x RJ-11
Type	Wireless
Security	WEP, WPA, WPA2, WPS
