46
12
Appendix
Technical Specifications
Item Specifications
Power supply 12 V DC, 1 A
Power consumption < 12 W
Ambient operating
temp
erature
0°C to 40°C
Ambient humidity 5% to 95% RH (non-condensing)
Dimensions (H x W x D)
5.12 mm x 32 mm x 162 mm (4.65 in. x 1.26 in. x 6.38 in.) antenna
excluded
Weight About 360 g
DSL standard
ADSL standard
ITU G.992.1
G.dmt
ITU G.992.2 (G.lite)
ITU G.994.1 (G.hs)
ANSI T1.413 Issue 2
ADSL2 standard
ITU G.992.3
G.dmt.bis
Annex L
ADSL2+ standard
ITU G.992.5
G.dmt.bitplus
VDSL2
ITU G.993.2 VDSL2
VDSL2 Profiles for 8a, 8b, 8c, 8d, 12a, 12b,
1
7a, 30a
VDSL Vectoring
DSL transmission rate
G.dmt
T1.413
Downlink: 8 Mbit/s
Uplink: 896 kbit/s
ADSL
Downlink: 12 Mbit/s
Uplink: 1024 kbit/s
ADSL2+
Downlink: 24 Mbit/s
Uplink: 1024 kbit/s

Table of Contents

Other manuals for Huawei HG658 V2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Huawei HG658 V2 and is the answer not in the manual?

Huawei HG658 V2 Specifications

General IconGeneral
ModelHG658 V2
CategoryGateway
Wi-Fi Standards802.11 b/g/n
Frequency Band2.4 GHz
Ethernet Ports4
USB Ports1
Wireless Speed300 Mbps
WLANYes
Number of LAN Ports4
LAN Port TypeRJ-45
Number of FXS Ports2
WAN Ports1 x RJ-11
TypeWireless
SecurityWEP, WPA, WPA2, WPS
