6
2
Hardware Installation
Selecting an Installation Location
Place the HG658 V2 on a well-ventilated even surface without exposure to direct sunlight. For the best
possible performance, take note of the following:
•
Make sure there are no obstacles, such as concrete or wooden walls, between the computer and
HG658 V2.
•
Ensure that the computer and HG658 V2 are far from electric appliances that generate strong
magnetic or electric fields, such as microwave ovens.
Installing the HG658 V2 on a DSL Broadband Network
In some communities, Internet service providers use telephone lines to provide broadband access
services.
If you have subscribed to digital subscriber line (DSL) broadband, you can connect the HG658 V2 to a
telephone port for Internet access.
Connect your devices in the sequence indicated in the following figure.
1 Telephone wall jack 2 Splitter 3 Telephone
4
Power
DSL LAN4 LAN3 LAN2 LAN1 Phone2 Phone1
6
3
8
9
10
1
2
a
b
7
5
c
To Next Page
