HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
and four SFP ports on the panel.
Provides an independently powered baseboard management controller
(BMC). The BMC connects to the SMM through the Network Controller
Sideband Interface (NC-SI) bus. The BMC provides the following
functions:
Manages the field replaceable unit (FRU) information, sensor data
records (SDRs), and system event logs (SELs).
Detects the board temperature and voltage, reports alarms, and
controls the power-on, power-off, hot swap, and reset operations of
the board.
Supports serial port redirection.
Loads board software online.
The boards are hot-swappable.
Appearance
The SPUA0s are half-width boards and installed in the front service board slots of the subrack.
Figure 1-34 shows an SPUA0.
Figure 1-34 Appearance (unit: mm)
Figure 1-35 shows the hardware structure of the SPUA0.
