Huawei SUN2000-12KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
7 Man-Machine Interaction
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
107
LCD
Procedure
3. Enter the correct user name and password
by pressing or , and press .
NOTE

The optional user names are Advanced User
and Special User. The initial password for
Advanced User and Special User is 000001. If
you forgot the password, contact Huawei
technical support for a dynamic password that is
effective only on the current day. Change the
password after login.

After the authentication is successful, the
system keeps the authentication information for
30 seconds. If you exit from the Maintenance
screen and log in again within 30 seconds, no
authentication is required.
4. Choose Alarm Reset, and press .
5. After alarms are reset, press .
----End
7.2.17 Resetting the System
You can reset the system on the LCD.
Context
The inverter automatically shuts down and restarts after a system reset.

Huawei SUN2000-12KTL Specifications

General

Max. Efficiency	98.6%
Rated AC Power Output	12, 000 W
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Protection Rating	IP65
Max. Input Voltage	1100 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	22 A
Cooling Method	Natural Convection
Max. apparent AC power	12000 VA
MPPT Voltage Range	200 V to 1, 000 V
Rated AC Voltage	220 V / 380 V, 230 V / 400 V, 240 V / 415 V
Warranty	5 years
