Huawei SUN2000-12KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
4 Installation
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
18
4 Installation
This chapter describes how to install the SUN2000.
Context

Do not install the SUN2000 on flammable building materials.

Do not store the SUN2000 in areas with flammable or explosive materials.
Do not install the SUN2000 in places prone to body contact because the SUN2000 shelf and
heat sinks become hot during the SUN2000 operation.
4.1 Checking Before Installation
Before unpacking, check that the outer packing is intact. After unpacking, check that the
product and accessories are intact and complete.
Checking Outer Packing Materials
Before unpacking the SUN2000, examine the outer packing for damage such as holes and
cracks. If any such damage is found, do not unpack the SUN2000 and contact the dealer
immediately.
Remove the outer packing only 24 hours before installation.

Huawei SUN2000-12KTL Specifications

General

Max. Efficiency	98.6%
Rated AC Power Output	12, 000 W
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Protection Rating	IP65
Max. Input Voltage	1100 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	22 A
Cooling Method	Natural Convection
Max. apparent AC power	12000 VA
MPPT Voltage Range	200 V to 1, 000 V
Rated AC Voltage	220 V / 380 V, 230 V / 400 V, 240 V / 415 V
Warranty	5 years
