Huawei SUN2000-12KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
B Power Grid Codes
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
127
B Power Grid Codes
Set the power grid code that applies to the country or region where the power station is
located and the SUN2000 model.
Low-voltage power grid codes apply to SUN2000 models including the SUN2000-8KTL,
10KTL, 12KTL, 15KTL, 17KTL, 20KTL, and 23KTL. Table B-1 describes the countries to
which low-voltage power grid codes apply.
Table B-1 Low-voltage power grid codes
No.
Power Grid Code
Country
1
NB/T 32004
China Golden Sun low-voltage power grid
2
UTE C 15-712-1(A)
France low-voltage power grid
3
UTE C 15-712-1(B)
Islands of France 230 V 50 Hz
4
UTE C 15-712-1(C)
Islands of France 230 V 60 Hz
5
VDE 0126-1-1-BU
Bulgaria low-voltage power grid
6
VDE 0126-1-1-GR(A)
Mainland of Greece low-voltage power grid
7
VDE 0126-1-1-GR(B)
Islands of Greece low-voltage power grid
8
BDEW-MV
Germany medium-voltage power grid (400
V AC)
9
VDE-AR-N-4105
Germany low-voltage power grid
10
G59-England
England 230 V power grid (I > 16 A)
11
G59-Scotland
Scotland 240 V power grid (I > 16 A)
12
G83-England
England 230 V power grid (I < 16 A)
13
G83-Scotland
Scotland 240 V power grid (I < 16 A)
14
EN50438-CZ
Czech Republic low-voltage power grid
15
RD1699
Spanish low-voltage power grid (Pn < 100
kW)
16
RD661
Spanish low-voltage power grid (Pn > 100

Huawei SUN2000-12KTL Specifications

General

Max. Efficiency	98.6%
Rated AC Power Output	12, 000 W
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Protection Rating	IP65
Max. Input Voltage	1100 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	22 A
Cooling Method	Natural Convection
Max. apparent AC power	12000 VA
MPPT Voltage Range	200 V to 1, 000 V
Rated AC Voltage	220 V / 380 V, 230 V / 400 V, 240 V / 415 V
Warranty	5 years
