Huawei SUN2000-12KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
B Power Grid Codes
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
128
No.
Power Grid Code
Country
kW)
17
EN50438-NL
Netherlands low-voltage power grid
18
C10/11
Belgium low-voltage power grid
19
AS4777
Australia low-voltage power grid
20
CEI0-16
Italian medium-voltage power grid
21
CEI0-21
Italian low-voltage power grid
22
ANRE
Romania low-voltage power grid
23
TAI-PEA
Thailand low-voltage power grid (PEA)
24
TAI-MEA
Thailand low-voltage power grid (MEA)
25
EN50438-TR
Turkey low-voltage power grid
26
Philippines
Philippines low-voltage power grid
27
NRS-097-2-1
South Africa low-voltage power grid
28
KOREA
South Korea low-voltage power grid
29
IEC61727
IEC low-voltage power grid (50 Hz)
30
IEC61727-60Hz
IEC low-voltage power grid (60 Hz)
31
Custom (50Hz)
Reserved
32
Custom (60Hz)
Reserved
Medium-voltage power grid codes apply to SUN2000 models including the SUN2000-28KTL.
Table B-2 describes the countries to which medium-voltage power grid codes apply.
Table B-2 Medium-voltage power grid codes
No.
Power Grid Code
Country
1
CHINA-MV480
China medium-voltage power grid
2
BDEW-MV480
Germany medium-voltage power
grid
3
G59-England-MV480
UK 480 V Medium-voltage power
grid (I > 16 A)
4
UTE C 15-712-1-MV480
France medium-voltage power grid
5
TAI-PEA-MV480
Thailand medium-voltage power grid
(PEA)
6
TAI-MEA-MV480
Thailand medium-voltage power grid
(MEA)

Huawei SUN2000-12KTL Specifications

General

Max. Efficiency	98.6%
Rated AC Power Output	12, 000 W
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Protection Rating	IP65
Max. Input Voltage	1100 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	22 A
Cooling Method	Natural Convection
Max. apparent AC power	12000 VA
MPPT Voltage Range	200 V to 1, 000 V
Rated AC Voltage	220 V / 380 V, 230 V / 400 V, 240 V / 415 V
Warranty	5 years
