Huawei SUN2000-12KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
8 Maintenance
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
114
Alarm ID
Name
Severity
Causes
Measures
200
DC Bus
Voltage
Fault
Major
Abnormal external conditions
have triggered DC circuit
protection inside the
SUN2000. The possible causes
are as follows:

Reason ID = 3
The SUN2000 input is
suddenly disconnected, or
the shielded PV strings
result in a sharp change in
output power.

Reason ID = 9 or 11
The input energy of the
SUN2000 cannot be vented
quickly due to the sharp
change of grid voltage. As
a result, the internal
voltage increases.

Reason ID = 10
The internal control circuit
of the SUN2000 is unable
to keep up with changes
due to grid phase
imbalances.
a. The SUN2000 monitors its
external working conditions in
real time and automatically
reverts to normal operating status
after the fault is rectified.
b. If the alarm occurs repeatedly,
contact Huawei technical
support.

Huawei SUN2000-12KTL Specifications

General

Max. Efficiency	98.6%
Rated AC Power Output	12, 000 W
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Protection Rating	IP65
Max. Input Voltage	1100 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	22 A
Cooling Method	Natural Convection
Max. apparent AC power	12000 VA
MPPT Voltage Range	200 V to 1, 000 V
Rated AC Voltage	220 V / 380 V, 230 V / 400 V, 240 V / 415 V
Warranty	5 years
