Huawei SUN2000-12KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
7 Man-Machine Interaction
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
69
Figure 7-1 Hierarchy of the Main Menu
The parameters vary with user types. The three types of user are Common User, Advanced
User, and Special User. Figure 7-2 and Figure 7-3 show the hierarchies under the Settings
and Maintenance menus.
The initial password for Common User, Advanced User, and Special User is 000001. Use
the initial password to log in to the SUN2000 for the first time and change the password
immediately (see 7.2.7 Changing a User Password) to ensure account safety.

Huawei SUN2000-12KTL Specifications

General

Max. Efficiency	98.6%
Rated AC Power Output	12, 000 W
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Protection Rating	IP65
Max. Input Voltage	1100 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	22 A
Cooling Method	Natural Convection
Max. apparent AC power	12000 VA
MPPT Voltage Range	200 V to 1, 000 V
Rated AC Voltage	220 V / 380 V, 230 V / 400 V, 240 V / 415 V
Warranty	5 years
