Huawei SUN2000-12KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
7 Man-Machine Interaction
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
84
LCD Screen
Procedure
2. Choose and press .
3. Enter the correct user name and password
by pressing or , and press .
NOTE

The optional user names are Common User and
Advanced User. The initial password for
Common User and Advanced User is 000001.
If you forgot the password, contact Huawei
technical support for a dynamic password that is
effective only on the current day. Change the
password after login.

After the authentication is successful, the
system keeps the authentication information for
30 seconds. If you exit from the Settings screen
and log in again within 30 seconds, no
authentication is required.
An Advanced User has logged in to the
SUN2000.
4. Choose User Param. and press .
5. Choose Contrast by pressing , and
press .

Huawei SUN2000-12KTL Specifications

General

Max. Efficiency	98.6%
Rated AC Power Output	12, 000 W
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Protection Rating	IP65
Max. Input Voltage	1100 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	22 A
Cooling Method	Natural Convection
Max. apparent AC power	12000 VA
MPPT Voltage Range	200 V to 1, 000 V
Rated AC Voltage	220 V / 380 V, 230 V / 400 V, 240 V / 415 V
Warranty	5 years
