Huawei SUN2000-12KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
7 Man-Machine Interaction
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
88
LCD Screen
Procedure
2. Choose and press .
3. Enter the correct user name and password
by pressing or , and press .
NOTE

The optional user names are Common User,
Advanced User, and Special User. The initial
password for these accounts is 000001. If you
forgot the password, contact Huawei technical
support for a dynamic password that is effective
only on the current day. Change the password
after login.

After the authentication is successful, the
system keeps the authentication information for
30 seconds. If you exit from the Settings screen
and log in again within 30 seconds, no
authentication is required.
4. Choose User Password by pressing ,
and press .
5. Enter the old password and press .
Increase or decrease the value by pressing
or . Switch between digits by pressing
.

Huawei SUN2000-12KTL Specifications

General

Max. Efficiency	98.6%
Rated AC Power Output	12, 000 W
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Protection Rating	IP65
Max. Input Voltage	1100 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	22 A
Cooling Method	Natural Convection
Max. apparent AC power	12000 VA
MPPT Voltage Range	200 V to 1, 000 V
Rated AC Voltage	220 V / 380 V, 230 V / 400 V, 240 V / 415 V
Warranty	5 years
