Huawei SUN2000-3KTL-M1 Series User Manual

● 4G Smart Dongle
Table 6-4 Indicator description
Indicators Status Remarks Description
- O Normal The Smart Dongle is
not secured or not
powered on.
Yellow
(blinking
green and red
simultaneousl
y)
Steady on Normal The Smart Dongle is
secured and powered
on.
Green The blinking
interval is 2s. The
indicator is on for
0.1s and then o
for 1.9s
alternately.
Normal Dialing (lasting for
less than 1 minute)
Abnormal If the duration is
longer than 1 minute,
the 4G parameter
settings are incorrect.
Reset the parameters.
Blinking at long
intervals (on for 1s
and then o for
1s)
Normal The dialup is
successful (lasting for
less than 30s).
Abnormal If the duration is
longer than 30s, the
management system
parameters are
incorrectly set. Reset
the parameters.
Steady on Normal Connected to the
management system.
Blinking at short
intervals (on for
0.2s and then o
for 0.2s)
The SUN2000
communicates with
the management
system through the
Smart Dongle.
Red Steady on Abnormal The Smart Dongle is
faulty. Replace the
Smart Dongle.
SUN2000-(3KTL-10KTL)-M1 Series
User Manual 6 Commissioning
Issue 17 (2024-01-12) Copyright © Huawei Technologies Co., Ltd. 80

Huawei SUN2000-3KTL-M1 Series Specifications

General

Max. efficiency	98.4%
European efficiency	97.8%
Rated AC output power	3000 W
Dimensions (W x H x D)	365 x 365 x 156 mm
Operating temperature range	-25°C to +60°C
Topology	Transformerless
Protection Degree	IP65
Number of MPP Trackers	2
Output Frequency	50 Hz / 60 Hz
Cooling Method	Natural Convection
Max. DC Power	4500 W
Max. Input Current	11 A
Power Factor	0.8 leading - 0.8 lagging
Max. apparent power	3300 VA
AC output voltage	220 V / 230 V / 240 V
