7.1.3 Creating a PV Plant and a User
Figure 7-5 Creating a PV plant and a user
NO TE
In the quick settings, the grid code is set to N/A by default (automatic startup is not
supported). Set the grid code based on the area where the PV plant is located.
For details about how to use the site deployment wizard, see
FusionSolar App Quick
Guide
. You can scan the QR code to download the quick guide.
7.1.4 (Optional) Setting the Physical Layout of the Smart PV
Optimizers
NO TE
If smart PV optimizers are congured for PV strings, ensure that the smart PV optimizers
have been successfully connected to the SUN2000 before performing the operations in
this section.
Check that the SN labels of smart PV optimizers are correctly attached to the physical
layout template.
Take and save a photo of the physical layout template. Keep your phone parallel to the
template and take a photo in landscape mode. Ensure that the four positioning points in
the corners are in the frame. Ensure that each QR code is attached within the frame.
For details about the physical layout of smart PV optimizers, see
FusionSolar App
Quick Guide
. You can scan the QR code to download the quick guide.
SUN2000-(3KTL-10KTL)-M1 Series
User Manual 7 Man-Machine Interaction
Issue 17 (2024-01-12) Copyright © Huawei Technologies Co., Ltd. 85
