SUN2000-(12KTL, 15KTL, 17KTL, 20KTL)-M0
User Manual
2 Overview
Issue 03 (2019-07-19)
Copyright © Huawei Technologies Co., Ltd.
5
Icon
Meaning
Description
2
Power level

8K: The rated power is 8 kW.

10K: The rated power is 10 kW.

12K: The rated power is 12 kW.

15K: The rated power is 15 kW.

17K: The rated power is 17 kW.

20K: The rated power is 20 kW.
3
Topology
TL: transformerless
4
Product code
M0: the product series with the 1100 V DC input
voltage
Network Application
The SUN2000 applies to grid-tied PV systems for residential rooftops and small ground plants.
Typically, a grid-tied system consists of the PV string, SUN2000, AC switch, and alternating
current distribution unit (ACDU).
Figure 2-2 Networking application (optional in dashed boxes)

indicates a power cable, indicates a signal cable, indicates wireless
communication.
