5.5 (Optional) Installing the Smart Dongle
Procedure

If the 4G Smart Dongle you purchase is configured with a SIM card, skip this step.

If it is not configured with a SIM card, prepare a standard one (dimensions: 25 mm x 15 mm,
capacity ≥ 64 KB.

When installing a SIM card, you can determine the SIM card installation direction based on the silk
screen and arrow mark on the slot.

When being pressed into place, the SIM card will be locked, which means that the card is installed
correctly.

To remove the SIM card, push it inwards. Then the SIM card springs out automatically.

When reinstalling the 4G Smart Dongle, ensure that the buckle springs back in place.
Step 1 Install the Smart Dongle.
Figure 5-16 Installing the Smart Dongle.
----End
5.6 (Optional) Installing the Signal Cable
Communication port signal definitions
