Huawei SUN2000-8KTL-M0 - Appearance

SUN2000-(12KTL, 15KTL, 17KTL, 20KTL)-M0
User Manual
2 Overview
Issue 03 (2019-07-19)
Copyright © Huawei Technologies Co., Ltd.
7
2.2 Appearance
Figure 2-4 Appearance
(1) LED indicator
(2) Front panel
(3) Mounting plate
(4) Heat sink
(5) Ventilation valve
(6) Ground screw
(7) AC output port (AC)
(8) Communication port (COM)
(9) Smart Dongle port (GPRS/4G/WLAN)
(10) DC input terminals (PV4+/PV4–)
(11) DC input terminals (PV3+/PV3–)
(12) DC input terminals (PV2+/PV2–)
(13) DC input terminals (PV1+/PV1–)
(14) DC switch (DC SWITCH)
Two M6 screw holes are reserved on the sides of the enclosure for installing an awning.
Table 2-2 LED indicator description
Category
Status
Meaning
Running
indication
LED1
LED2
N/A
Steady green
Steady green
The SUN2000 is operating in
grid-tied mode.
