Table 2-1 Model description
Icon Meaning Description
1 Product family SUN2000: three-phase grid-tied PV string inverter
2 Power level ● 8K: The rated power is 8 kW.
● 10K: The rated power is 10 kW.
● 12K: The rated power is 12 kW.
● 15K: The rated power is 15 kW.
● 17K: The rated power is 17 kW.
● 20K: The rated power is 20 kW.
3 Topology TL: transformerless
4 Product code M2: the product series with the 1080 V DC input voltage
Network Application
The SUN2000 applies to grid-tied PV systems for residential rooftops and small
ground plants. Typically, a grid-tied system consists of the PV string, SUN2000, AC
switch, and alternating current distribution unit (ACDU).
Figure 2-2 Networking application - Single inverter scenario (optional in dashed
boxes)
SUN2000-(8KTL-20KTL)-M2
User Manual 2 Overview
Issue 11 (2023-02-07) Copyright © Huawei Technologies Co., Ltd. 14
