SUN2000-(12KTL, 15KTL, 17KTL, 20KTL)-M0
User Manual
5 Electrical Connections
Issue 03 (2019-07-19)
Copyright © Huawei Technologies Co., Ltd.
31
No.
Component
Description
Source
C
Smart Dongle
a

WLAN Smart Dongle:
SDongleA-01.

4G Smart Dongle:
SDongleA-03.
Purchased from
Huawei
D
SUN2000
Select a proper model based on
requirements.
Purchased from
Huawei
E
SmartLogger10
00A
Select a proper model based on
requirements.
Purchased from
Huawei
F
Smart Power
Sensor
The recommended electricity meter
model is DTSU666-H.
Purchased from
Huawei
G
Ripple Control
Device
Select the devices that meet the
power grid scheduling
requirements.
Provided by local
power grid
companies
H
AC switch
b
Recommended: a three-phase AC
circuit breaker with a rated voltage
greater than or equal to 415 V AC
and a rated current of:

25 A (SUN2000-8KTL-M0,
SUN2000-10KTL-M0,
SUN2000-12KTL-M0)

40 A (SUN2000-15KTL-M0,
SUN2000-17KTL-M0,
SUN2000-20KTL-M0)
Prepared by the
customer

Note a: WLAN Smart Dongle: For details about the SDongleA-01 operation, see
SDongleA-01 Quick Guide (WLAN); 4G Smart Dongle: For details about the
SDongleA-03 operation, see SDongleA-03 Quick Guide (4G). You can obtain the quick
guide at https://support.huawei.com/enterprise by searching for the Smart Dongle
model.

Note b：The SUN2000-8KTL-M0 and SUN2000-10KTL-M0 inverters are applicable
only to Australia.
Table 5-2 Cable description
No.
Name
Type
Specifications
1
DC input power cable
Standard PV cable in the
industry

Conductor
cross-sectional area:
4–6 mm
2

Cable outer diameter:
4.5–7.8 mm
