Figure 4-9 Installing expansion bolts
Step 3 (Optional) Install the locking screw for the DC switch.
Figure 4-10 Installing a locking screw for the DC switch
Step 4 Install the SUN2000 on the mounting bracket.
Step 5 Tighten the nuts.
Figure 4-11 Tightening nuts
Step 6 (Optional) Install an anti-theft lock.
● Prepare an anti-theft lock suitable for the lock hole diameter (Ф10 mm).
● An outdoor waterproof lock is recommended.
● Keep the key to the anti-theft lock.
SUN2000-(2KTL-6KTL)-L1
User Manual 4 System Installation
Issue 04 (2021-04-01) Copyright © Huawei Technologies Co., Ltd. 26
