Huawei UPSJZ-T Series User Manual

Install an optional communications card for the UPS. For details, see the RMS-
SNMP01B SNMP Card User Manual , RMS-RELAY01B User Manual , and RMS-
MODBUS01B User Manual .
Figure 3-6 Installing optional cards for UPSs (standard backup time models)
Figure 3-7 Installing optional cards for UPSs (long backup time models)
NO TE
The UPS provides an optional intelligent slot for installing an SNMP card, a dry contact
card, or a Modbus card. Any card supports advanced communication functions and multiple
monitoring options.
Step 4 Connect communications cables.
Connect the UPS to a PC over a USB or RS232 port to monitor the UPS running
status.
UPSJZ-T-(1 kVA–3 kVA)
User Manual 3 Installation
2022-08-15 27
