4 Control Panel
4.1 LCD
The UPS control panel is located on the front panel of the chassis. The control
panel allows you to control and operate the UPS, view the running status, set
parameters, and view alarms.
Figure 4-1 LCD control panel
Table 4-1 Icon description
Display
Function
Backup time information
UPSJZ-T-(1 kVA–3 kVA)
User Manual 4 Control Panel
2022-08-15 31
