● Minimum input voltage in bypass mode setting
Display Description
You can adjust the minimum input
voltage in bypass mode using ▲ and
▼.
170–220: The voltage can be set from
170 V AC (default) to 220 V AC.
The minimum input voltage in bypass mode must be lower than the minimum voltage
allowed in ECO mode.
● Battery capacity setting
Display Description
You can adjust and set the UPS battery
capacity using ▲ and ▼.
18–999: The capacity can be set from
18 Ah to 999 Ah. (The value is xed at
9 Ah for the UPS with standard backup
time, and the default value is 18 Ah
for the UPS with long backup time.)
● Discharge time limit setting
Display
Description
Set the discharge time limit:
0–999: The time can be set from 0
minutes to 999 minutes.
0: The backup time is not limited
(default).
● ECO mode enable/disable
UPSJZ-T-(1 kVA–3 kVA)
User Manual 4 Control Panel
2022-08-15 41
