Huawei WS322 User Manual

WS322 300Mbps Wireless Range Extender
User Guide
1 Product Overview
1-3
Table 1-1 WS322 ports and buttons
Item Functions
Power plug Can be plugged into a power socket.
WPS button Quickly sets up a wireless connection or changes WS322's
working mode.
Reset button After the WS322 is powered on, press and hold the Reset button
for 6s or more to restore the WS322 to its factory settings.
Restoring the WS322 to its factory settings will erase your
user-defined data.
Status
indicator
Shows the WS322 working status. For details, see section 1.2.2
Indicators.
Signal
strength
indicator
Shows the network signal strength. For details, see section 1.2.2
Indicators.
ETH port Connects the WS322 to a network device.
Table 1-2 Using the WPS Button for Quick Configuration
Function Operation
WPS
connection
Press and hold the WPS button more than 1 second and less than
3 seconds, and press the wireless client's WPS button within 2
minutes.
When the
status indicator turns from blinking to steady on,
the connection is set up.

Huawei WS322 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Rack mounting	No
Bandwidth (first)	2.4 GHz
Ethernet LAN (RJ-45) ports	1
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, TKIP, WEP, WPA-PSK, WPA2-PSK, WPS
Certification	CCC, CE, FCC, RoHS
AC input voltage	100 - 240 V
Power consumption (typical)	5 W
Storage temperature (T-T)	5 - 95 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	30.7 mm
Width	73 mm
Weight	200 g
