Huawei WS322 User Manual

8 Maintenance Guide
WS322 300Mbps Wireless Range Extender
User Guide
8-2
8.2 Changing the IP Address Used to Log In to
the Web management page
The IP address used to log in to the WS322 web management page is the WS322 IP
address. For security or other purposes (for instance, if the default WS322 IP address
conflicts with that of another device on the same network), you can change the
WS322 IP address.
Use the new IP address to log in to the web management page.
Step 1 Log in to the web management page.
Step 2 Click Advance Settings.
Step 3 In the navigation tree, choose Basic > LAN setting.
Step 4 Click DHCP Sever.
Step 5 In IP address under the LAN Host Settings group box, enter the new IP
address 192.168.3.88 in IP address.
Step 6 Click Submit.

Huawei WS322 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Rack mounting	No
Bandwidth (first)	2.4 GHz
Ethernet LAN (RJ-45) ports	1
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, TKIP, WEP, WPA-PSK, WPA2-PSK, WPS
Certification	CCC, CE, FCC, RoHS
AC input voltage	100 - 240 V
Power consumption (typical)	5 W
Storage temperature (T-T)	5 - 95 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	30.7 mm
Width	73 mm
Weight	200 g
