PSP8620311
Rev. E
47
NOTE: Because Hubbell has a policy of continuous product improvement,
we reserve the right to change design and specications without notice.
Return Kit
Packaging Instructions: Versa-Tech
®
Recloser
SPECIAL INSTRUCTIONS (MUST be done for proper shipment):
1. Components must be packaged exactly as shown above. Return Kit includes: Foam inserts, the outer
carton (same as the Return Kit was shipped in) and Class 9 Material Label.
Recloser with battery bayonet must be shipped per Department of Transportation (DOT) rules for lithium
batteries. Lithium batteries are considered a Class 9 material for shipment.
2. Ensure the battery bayonet containing the batteries is returned in the original shipping container (corrugated
box indicated in Photo B above, but not provided in the Return Kit) or in the receptacle of the Versa-Tech
recloser (indicated in Photo B above).
3. On the outer carton, apply the Class 9 label (provided in the return kit) on the same side of the carton
imprinted with "LITHIUM BATTERIES PACKED WITH EQUIPMENT UN 3091".
Photo C
Top foam insert
Battery Bayonet
original corrugated box
(NOT in Return Kit)
Battery Bayonet
receptacle
Photo B
Recloser placed
inside the bottom foam
Photo A
Bottom foam insert
To Next Page
