Electronic Overspeed Switch EGS 40
12
EGS40_MANUAL-en_R6(2018-11-07)ID74528.docx
3.3.5 Degree of protection
Protection class acc. to
DIN EN 60529
Sealing
Permissible
speed
Rotor moment of
inertia
Breakaway torque
EGS 40
IP65
Standard
≤ 6000 rpm
approx. 510 gcm²
approx. 6 Ncm
IP66
with labyrinth seal
≤ 6000 rpm
approx. 580 gcm²
approx. 6 Ncm
B5 IP66/IP67
B5/B14 IP66
with axial shaft seal
with axial shaft seal
B14
≤ 4000 rpm
approx. 510 gcm²
B5 approx. 8 Ncm
B5 IP66/IP67
B5/B14 IP66
with radial shaft seal
(for special
applications, e.g. wet
areas in rolling mills)
B14 axial shaft seal
≤ 3000 rpm
approx. 510 gcm²
B5 approx. 9 Ncm
EGSH 40
IP65
Standard
≤ 4000 rpm
approx. 1175
gcm²
approx. 10 Ncm
IP66
with labyrinth seal
≤ 4000 rpm
approx. 1325
gcm²
approx. 10 Ncm
IP66
with axial shaft seal
≤ 2000 rpm
approx. 1175
gcm²
approx. 25 Ncm
IP66
with radial shaft seal
(for special
applications, e.g. wet
areas in rolling mills)
≤ 2000 rpm
approx. 1175
gcm²
approx. 30 Ncm
NOTES!
If the cover plate is not fitted to the hollow shaft device EGS
®
40 the IP rating is
reduced to IP65.
NOTES!
At maximum speed the permissible ambient temperature will be reduced to 60°C.
