Part 2: HuddleCamHD VISCA Command List
Command
Function
Command Packet
Comments
CAM_Power
On
8x 01 04 00 02 FF
Power On/Off
Off
8x 01 04 00 03 FF
CAM_Zoom
Stop
8x 01 04 07 00 FF
Tele (Standard)
8x 01 04 07 02 FF
Wide (Standard)
8x 01 04 07 03 FF
Tele (Variable)
8x 01 04 07 2p FF
p = 0 (low) – 7 (high)
Wide (Variable)
8x 01 04 07 3p FF
Direct
8x 01 04 47 p q r s FF
CAM_Focus
Stop
8x 01 04 08 00 FF
Far (Standard)
8x 01 04 08 02 FF
Near (Standard)
8x 01 04 08 03 FF
Far (Variable)
8x 01 04 08 2p FF
p = 0 (low) – 7 (high)
Near (Variable)
8x 01 04 08 3p FF
Direct
8x 01 04 48 0p 0q 0r 0s FF
pqrs: Zoom Position
(0x04 0x00 0x00 0x00 = Full Zoom in.
0x00 0x00 0x00 0x00 = Full Zoom out.)
Auto Focus
8x 01 04 38 02 FF
Auto Focus On / Off
Manual Focus
8x 01 04 38 03 FF
Auto / Manual
8x 01 04 38 10 FF
Focus Lock
8x 0a 04 68 02 FF
Prevents any other operation or command
from adjusting the current focus state.
Focus Unlock
8x 0a 04 68 03 FF
CAM_WB
Auto
8x 01 04 35 00 FF
Normal Auto mode
Indoor
8x 01 04 35 01 FF
Indoor mode
Outdoor
8x 01 04 35 02 FF
Outdoor mode
OnePush
8x 01 04 35 03 FF
One Push White Balance mode
Manual
8x 01 04 35 05 FF
Manual control mode
ColorTemperature (VAR)
8x 01 04 35 20 FF
Color Temperature mode
OnePush Trigger
8x 01 04 10 05 FF
One Push White Balance Trigger
CAM_RGain
Reset
8x 01 04 03 00 FF
Manual control of red gain
Up
8x 01 04 03 02 FF
Down
8x 01 04 03 03 FF
Direct
8x 01 04 43 00 00 0p 0q FF
pq: Red Gain
CAM_BGain
Reset
8x 01 04 04 00 FF
Manual control of blue gain
Up
8x 01 04 04 02 FF
Down
8x 01 04 04 03 FF
Direct
8x 01 04 44 00 00 0p 0q FF
pq: Blue Gain
CAM_ColorTemp
Reset
8x 01 04 20 00 FF
Default ColorTemperature settings
Up
8x 01 04 20 02 FF
Down
8x 01 04 20 03 FF
Direct
8x 01 04 20 0p 0q FF
pq: ColorTemperature position: 0x00:
2500K ~ 0x37: 8000K
CAM_AE
Full Auto
8x 01 04 39 00 FF
Automatic Exposure mode
Manual
8x 01 04 39 03 FF
Manual exposure mode
Shutter Priority
8x 01 04 39 0A FF
Shutter priority auto exposure mode
Iris Priority
8x 01 04 39 0B FF
Iris priority auto exposure mode
Bright
8x 01 04 39 0D FF
Bright manual exposure mode
CAM_Iris
Reset
8x 01 04 0B 00 FF
Default Iris position
Up
8x 01 04 0B 02 FF
Iris setting
Down
8x 01 04 0B 03 FF
Direct
8x 01 04 4B 00 00 0p 0q FF
pq: Iris position
CAM_Shutter
Reset
8x 01 04 0A 00 FF
Default shutter position
Up
8x 01 04 0A 02 FF
Shutter setting
Down
8x 01 04 0A 03 FF
Direct
8x 01 04 4A 00 00 0p 0q FF
pq: Shutter position
CAM_Bright
Reset
8x 01 04 0D 00 FF
Default Bright position
