25
Rev 1.0 9/21
Navigate Down
8x 01 06 01 0E 0E 03 02 FF
Navigate Left
8x 01 06 01 0E 0E 01 03 FF
Navigate Right
8x 01 06 01 0E 0E 02 03 FF
Enter
8x 01 06 06 05 FF
Return
8x 01 06 06 04 FF
CAM_NDIMode
High
8x 0B 01 01 FF
Medium
8x 0B 01 02 FF
Low
8x 0B 01 03 FF
Off
8x 0B 01 04 FF
CAM_Multicast
Mode
Multicast Mode
8x 0B 01 23 0p FF
p=1: On, p=2: Off
CAM_PTZMotion
Sync
PTZ Motion Sync On
8x 0A 11 13 02 FF
PTZ Motion Sync Off
8x 0A 11 13 03 FF
PTZ MS Upper Speed Limit
8x 0A 11 14 pq FF
pq: Speed stage
PTZ MS Lower Speed Limit
8x 0A 11 14 pq FF
CAM_UACStatus
Toggle USB Audio
8x 2a 02 a0 04 0p FF
p=2: On, p=3: Off
x = Camera Address + 8
Part 3: HuddleCamHD VISCA Query Command List
CAM_PowerInq
8x 09 04 00 FF
y0 50 02 FF
On
y0 50 03 FF
Off (Standby)
y0 50 04 FF
Internal Power Circuit Error
CAM_ZoomPosInq
8x 09 04 47 FF
y0 50 0p 0q 0r 0s FF
pqrs: Zoom position
CAM_FocusAFModeInq
8x 09 04 38 FF
y0 50 02 FF
Auto Focus
y0 50 03 FF
Manual Focus
CAM_FocusPosInq
8x 09 04 48 FF
y0 50 0p 0q 0r 0s FF
pqrs: Focus Position
CAM_WBModeInq
8x 09 04 35 FF
y0 50 00 FF
Auto
y0 50 01 FF
Indoor
y0 50 02 FF
Outdoor
y0 50 03 FF
OnePush
y0 50 05 FF
Manual
y0 50 20 FF
ColorTemperature
CAM_RGainInq
8x 09 04 43 FF
y0 50 00 00 0p 0q FF
pq: Red Gain
CAM_BGainInq
8x 09 04 44 FF
y0 50 00 00 0p 0q FF
pq: Blue Gain
CAM_ColorTempInq
8x 09 04 20 FF
y0 50 pq FF
pq: ColorTemperature position
CAM_AEModeInq
8x 09 04 39 FF
y0 50 00 FF
Full Auto
y0 50 03 FF
Manual
y0 50 0A FF
Shutter Priority (SAE)
y0 50 0B FF
Iris Priority (AAE)
y0 50 0D FF
Bright
CAM_ShutterPosInq
8x 09 04 4A FF
y0 50 00 00 0p 0q FF
pq: Shutter position
CAM_IrisPosInq
8x 09 04 4B FF
y0 50 00 00 0p 0q FF
pq: Iris position
CAM_BrightPosInq
8x 09 04 4D FF
y0 50 00 00 0p 0q FF
pq: Bright position
CAM_ExpCompModeInq
8x 09 04 3E FF
y0 50 02 FF
On
y0 50 03 FF
Off
CAM_ExpCompPosInq
8x 09 04 4E FF
y0 50 00 00 0p 0q FF
pq: ExpComp position
CAM_BacklightModeInq
8x 09 04 33 FF
y0 50 02 FF
On
y0 50 03 FF
Off
CAM_Noise2DModeInq
8x 09 04 50 FF
y0 50 02 FF
Auto Noise 2D
y0 50 03 FF
Manual Noise 2D
CAM_Noise2DLevel
8x 09 04 53 FF
y0 50 0p FF
Noise Reduction (2D) p: 0 to 5
CAM_Noise3DLevel
8x 09 04 54 FF
y0 50 0p FF
Noise Reduction (3D) p: 0 to 5
CAM_FlickerModeInq
8x 09 04 55 FF
y0 50 0p FF
p=0: Off, 1: 50Hz, 2: 60Hz
CAM_ApertureModeInq
(Sharpness)
8x 09 04 05 FF
y0 50 02 FF
Auto Sharpness
y0 50 03 FF
Manual Sharpness
CAM_ApertureInq (Sharpness)
8x 09 04 42 FF
y0 50 00 00 0p 0q FF
pq: Aperture gain
SYS_MenuModeInq
8x 09 06 06 FF
y0 50 02 FF
On
