HuddleCamHD SimplTrack Lite - Page 29

28
Rev 1.0 9/21
Up
81 01 04 0D 02 FF
Bright setting
Down
81 01 04 0D 03 FF
Direct
81 01 04 0D 00 00 0p 0q FF
pq: Bright position
CAM_ExpComp
On
81 01 04 3E 02 FF
Exposure Compensation On / Off
Off
81 01 04 3E 03 FF
Reset
81 01 04 0E 00 FF
Default ExpComp position
Up
81 01 04 0E 02 FF
ExpComp setting
Down
81 01 04 0E 03 FF
Direct
81 01 04 4E 00 00 0p 0q FF
pq: ExpComp position
CAM_Backlight
On
81 01 04 33 02 FF
Backlight Compensation On / Off
Off
81 01 04 33 03 FF
CAM_Flicker
81 01 04 23 0p FF
p: Flicker settings - (0: Off, 1: 50Hz, 2: 60Hz)
CAM_Picture Effect
Off
81 01 04 63 00 FF
Picture Effect setting
B&W
81 01 04 63 04 FF
CAM_Memory
Reset
81 01 04 3F 00 pp FF
pp: Memory number (=0 to 127)
Set
81 01 04 3F 01 pp FF
Recall
81 01 04 3F 02 pp FF
Preset_Recall_
Speed
Preset Speed
81 01 06 01 p FF
P: Speed grade (0x01 ~ 0x18)
CAM_LR_ Reverse
On
81 01 04 61 02 FF
Image Flip Horizontal On / Off
Off
81 01 04 61 03 FF
CAM_PictureFlip
On
81 01 04 66 02 FF
Image Flip Vertical On / Off
Off
81 01 04 66 03 FF
CAM_ColorGain
Direct
81 01 04 49 00 00 00 0p FF
P: Color Gain setting 0h (60%) to Eh(200%)
Pan_TiltDrive
Up
81 01 06 01 VV WW 03 01 FF
VV: Pan Speed 0x01 (low) to 0x18 (high)
WW: Tilt Speed 0x01 (low) to 0x14
(high)
Down
81 01 06 01 VV WW 03 02 FF
Left
81 01 06 01 VV WW 01 03 FF
Right
81 01 06 01 VV WW 02 03 FF
UpLeft
81 01 06 01 VV WW 01 01 FF
UpRight
81 01 06 01 VV WW 02 01 FF
DownLeft
81 01 06 01 VV WW 01 02 FF
DownRight
81 01 06 01 VV WW 02 02 FF
Stop
81 01 06 01 VV WW 03 03 FF
AbsolutePosition
81 01 06 02 VV WW 0Y 0Y 0Y
0Y 0Z 0Z 0Z 0Z FF
YYYY: Pan position, ZZZZ: Tilt position
RelativePosition
81 01 06 03 VV WW 0Y 0Y 0Y
0Y 0Z 0Z 0Z 0Z FF
Home
81 01 06 04 FF
Reset
81 01 06 05 FF
Pan_TiltLimitSet
LimitSet
81 01 06 07 00 0W 0Y 0Y 0Y
0Y 0Z 0Z 0Z 0Z FF
W: 1 (UpRight), 0: DownLeft
YYYY: Pan position, ZZZZ: Tilt position
LimitClear
81 01 06 07 01 0W 07 0F 0F
0F 07 0F 0F 0F FF
CAM_Brightness
Direct
81 01 04 A1 00 00 0p 0q FF
pq: Brightness position
CAM_Contrast
Direct
81 01 04 A2 00 00 0p 0q FF
pq: Contrast position
CAM_Flip
Off
81 01 04 A4 00 FF
Single Command for video flip
Flip-H
81 01 04 A4 01 FF
Flip-V
81 01 04 A4 02 FF
Flip-HV
81 01 04 A4 03 FF
CAM_SettingSave
Save
81 01 04 A5 10 FF
Save Current Setting
CAM_AWB
Sensitivity
High
81 01 04 A9 00 FF
Normal
81 01 04 A9 01 FF
Low
81 01 04 A9 02 FF
CAM_AFZone
Top
81 01 04 AA 00 FF
AF Zone weight select
Center
81 01 04 AA 01 FF
Bottom
81 01 04 AA 02 FF
CAM_ColorHue
Direct
81 01 04 4F 00 00 00 0p FF
P: Color Hue setting 0h (-14°) to Eh (+14°)
OSD_Control
Open / Close
81 01 04 3F 02 5F FF
Navigate Up
81 01 06 01 0E 0E 03 01 FF
