CAM_PictureEffectModeInq
81 09 04 63 FF
y0 50 02 FF
Off
y0 50 04 FF
B&W
CAM_LR_ReverseInq
81 09 04 61 FF
y0 50 02 FF
On
y0 50 03 FF
Off
CAM_PictureFlipInq
81 09 04 66 FF
y0 50 02 FF
On
y0 50 03 FF
Off
CAM_ColorGainInq
81 09 04 49 FF
y0 50 00 00 00 0p FF
P: Color gain 0h (60%) to Eh (200%)
CAM_PanTiltPosInq
81 09 06 12 FF
y0 50 0w 0w 0w 0w 0z 0z 0z
0z FF
WWWW: Pan position, ZZZZ: Tilt position
CAM_GainLimitInq
81 09 04 2C FF
y0 50 0q FF
p: Gain limit
CAM_AFSensitivityInq
81 09 04 58 FF
y0 50 01 FF
High
y0 50 02 FF
Normal
y0 50 03 FF
Low
CAM_BrightnessInq
81 09 04 A1 FF
y0 50 00 00 0p 0q FF
pq: Brightness position
CAM_ContrastInq
81 09 04 A2 FF
y0 50 00 00 0p 0q FF
pq: Contrast position
CAM_FlipInq
81 09 04 A4 FF
y0 50 00 FF
Off
y0 50 01 FF
Flip-H
y0 50 02 FF
Flip-V
y0 50 03 FF
Flip-HV
CAM_AFZone
81 09 04 AA FF
y0 50 00 FF
Top
y0 50 01 FF
Center
y0 50 02 FF
Bottom
CAM_ColorHueInq
81 09 04 4F FF
y0 50 00 00 00 0p FF
P: Color Hue 0h (-14°) to Eh (+14°)
CAM_AWBSensitivityInq
81 09 04 A9 FF
y0 50 00 FF
High
y0 50 01 FF
Normal
y0 50 02 FF
Low
CAM_UACInq
81 2A 02 A0 04
FF
y0 50 02 FF
On
y0 50 03 FF
Off
Block Inquiry Command List
Command
Command Packet
Inquiry Packet
Comments
CAM_LensBlockInq
81 09 7E 7E 00 FF
y0 50 0u 0u 0u 0u 00 00 0v 0v
0v 0v 00 0w 00 FF
UUUU: Zoom position
VVVV: Focus position
W.bit0: Focus mode 1: Auto, 0:
manual
CAM_CameraBlockInq
81 09 7E 7E 01 FF
y0 50 0p 0p 0q 0q 0r 0s tt 0u
vv ww 00 xx 0z FF
PP: Red Gain,
QQ: Blue Gain
R: WB Mode,
S: Aperture
TT: AE Mode,
U.bit2: Backlight
U.bit1: Exposure Comp,
VV: Shutter position.
WW: Iris position,
XX Bright position,
Z: Exposure Comp position
CAM_OtherBlockInq
81 09 7E 7E 02 FF
y0 50 0p 0q 00 0r 00 00 00 00
00 00 00 00 00 FF
P.bit0: Power 1: On, 0: Off
Q.bit2: LR Reverse: 1: On, 0: Off
R.bit3~0: Picture Effect Mode
CAM_EnlargmentBlockInq
81 09 7E 7E 03 FF
y0 50 00 00 00 00 00 00
00 0p 0q rr 0s 0t 0u FF
P: AF sensitivity
Q.bit0: Picture flip: 1: On, 0: Off
RR.bit6~3: Color Gain (0h (60%)
to Eh (200%))
S: Flip 0: Off, 1: Flip-H, 2: FlipV, 3:
Flip-HV
T.bit2~0: NR2D level
U: Gain limit
