Humminbird HELIX CHIRP GPS G2N User Manual

141
Customize the Chart View
Show/Hide the Course Projection Line
The course projection line is an arrow or line extending from the bow of the boat icon. It projects the current course and shows
where the boat will go if you continue on your present course.
1. Main Menu: Press the MENU key twice. Select the Nav tab.
2. Select Course Projection Line.
3. Select a display setting.
Hidden The Course Projection line will not be displayed.
Standard arrow
Single Vector line
COG/SOG
A line with tick marks will be displayed at set intervals from the boat. The tick marks are based
on the speed calculation.
Show/Hide Latitude/Longitude Lines
Use the following instructions to show or hide latitude and longitude lines on the Chart View.
1. Main Menu: Press the MENU key twice. Select the Chart tab.
2. Select Lat/Lon Grid.
3. Select Visible or Hidden.
Adjust the Depth Shading
Shaded Depth allows you to change the depth used for shading on the Chart View. The available settings are determined by the
installed map card and selected map source.
1. Main Menu: Press the MENU key twice. Select the Chart tab.
2. Select Shaded Depth.
3. Press the RIGHT or LEFT Cursor keys to adjust the setting.

Humminbird HELIX CHIRP GPS G2N Specifications

General

Display Size	7 inches
Waypoints	2, 500
Routes	50
Track Points	50, 000
Networking	Ethernet
Display Type	Color TFT
Down Imaging	Yes
Side Imaging	Yes
Chartplotting	Yes
LakeMaster Compatibility	Yes
AutoChart Live	Yes
NMEA0183	Yes
NMEA2000	Yes
Power Output	500 Watts (RMS)
Storage Temperature	-20°C to 70°C
Water Rating	IPX7
Display Resolution	800H x 480V
Sonar	CHIRP Digital Sonar
GPS	Internal
Display Pixel Matrix	800H x 480V
Card Slots	microSD
Max Depth	1500 ft
Frequency	83/200 kHz & 455/800 kHz
