Sonar (2D)
A S   F
(S X-P M)
The X-Press Menu provides menu options to adjust the sensitivity and range as you fish. You can also control how fast the sonar
history scrolls across the screen. The menus allow you to see more or less of the sonar returns from the transducer beams as you
adjust each setting. Also, you can use key shortcuts on the view.
Adjusting Settings from the Sonar X-Press Menu (HELIX 7 CHIRP SI GPS G2)
upper range
chart speed
RTS Window
lower range
surface
clutter
