Humminbird HELIX CHIRP GPS G2N User Manual

5
Manage your Navigation Data 176
Manage Waypoints .....................................179
Manage Routes ........................................183
Manage Tracks .........................................190
Manage Groups ........................................192
Search and Organize ...................................196
Import/Export Navigation Data ..........................198
Delete All Navigation Data and Reset .....................198
AutoChart Live Overview 199
Plan your Map .........................................199
Prepare the Control Head for Mapping ....................200
Record your Custom Map ...............................203
Stop Recording ........................................204
Correct Data ...........................................204
Using AutoChart Live in Ice Fishing Mode .................205
Open the AutoChart Live Menu ...........................206
Display the AutoChart Live Map ..........................206
Customize the AutoChart Live Map Display Settings .......208
Customize the Bottom Hardness Display Settings .........213
Customize the Vegetation Display Settings ...............217
Set Up a NMEA 2000 Network 221
Understand the NMEA 2000 Instrument View .............225
Manage your Control Head 226
Maintenance 232
Troubleshooting 233
Specifications 235
Statements and Acknowledgements 328
Contact Humminbird 330
T  C

Humminbird HELIX CHIRP GPS G2N Specifications

General

Display Size	7 inches
Waypoints	2, 500
Routes	50
Track Points	50, 000
Networking	Ethernet
Display Type	Color TFT
Down Imaging	Yes
Side Imaging	Yes
Chartplotting	Yes
LakeMaster Compatibility	Yes
AutoChart Live	Yes
NMEA0183	Yes
NMEA2000	Yes
Power Output	500 Watts (RMS)
Storage Temperature	-20°C to 70°C
Water Rating	IPX7
Display Resolution	800H x 480V
Sonar	CHIRP Digital Sonar
GPS	Internal
Display Pixel Matrix	800H x 480V
Card Slots	microSD
Max Depth	1500 ft
Frequency	83/200 kHz & 455/800 kHz
