77
Down Imaging Sonar
For more information, see
the Sonar and Navigation sections.
Chart > Chart/Sonar/Down Combo View
(Map Source: Contour XD)
For more information, see
Navigation Overview.
Chart > Chart/Down Combo View
(Map Source: Contour XD)
NOTE: The available views are determined by your control head model and the installed transducer. For a complete list of the
views available on your control head, press the MENU key twice, and select the Views tab. See each related section of the manual
(Views, Sonar, Side Imaging, Navigation Overview, etc.) for more information.
