80
Down Imaging Sonar
Change the View Colors
The DI Colors menu changes the palette used to display sonar returns on the view.
Down Imaging View with Palette 10 Selected (DI Colors)
Change the Down Imaging Colors Palette
1. Down Imaging X-Press Menu: With a Down Imaging View displayed on-screen, press the MENU key once.
2. Select DI Colors.
3. Select a palette.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Humminbird HELIX CHIRP GPS G2N and is the answer not in the manual?

Humminbird HELIX CHIRP GPS G2N Specifications

General IconGeneral
Display Size7 inches
Waypoints2, 500
Routes50
Track Points50, 000
NetworkingEthernet
Display TypeColor TFT
Down ImagingYes
Side ImagingYes
ChartplottingYes
LakeMaster CompatibilityYes
AutoChart LiveYes
NMEA0183Yes
NMEA2000Yes
Power Output500 Watts (RMS)
Storage Temperature-20°C to 70°C
Water RatingIPX7
Display Resolution800H x 480V
SonarCHIRP Digital Sonar
GPSInternal
Display Pixel Matrix800H x 480V
Card SlotsmicroSD
Max Depth1500 ft
Frequency83/200 kHz & 455/800 kHz
