INSTALLATION
16
Attach the Hold-Down Brackets (Optional)
Use a ballpoint pen or similar pointed object to create a center hole in each of the bottom
rail end caps for the hold-down pins to be inserted.
Insert a hold-down pin into each of the holes in the bottom rail end caps.
Mark the screw holes on the mounting surface.
Attach the hold-down brackets to the jamb, sill, or outside mounting surface. When the
blind is fully lowered, the holes in the hold-down brackets must align with the hold-down
pins in the bottom rail end caps.
Insert the hold-down pins into the holes of the hold-down brackets.
Attach the SimpleLift
™
Hold-Down Brackets (Optional)
Lower the blind and place the pins from the hold-down brackets into the bottom rail
end caps.
Mark the screw holes on the mounting surface.
Check that the hold-down brackets are aligned and attach them using the two screws
provided.
Jamb Mount
Outside Mount
Hold-Down Pin
Bottom Rail End Cap
Outside Mount
Sill
To Next Page
