INSTALLATION
7
Mount the Beveled Box Installation Brackets
— Inside or Ceiling Mount (Commercial Applications)
Bracket Shims (Optional)
Bracket shims are used to gain clearance for
inside or ceiling mount blinds.
NOTE: Bracket shims may also be used
to level the blind whenever the mounting
surface is uneven.
Attach the Beveled Box Installation Brackets
With inside or ceiling mounts, attach the two beveled box installation brackets flush against
the sides of the window casement or to the ceiling. Choose the most appropriate of the
following mounting methods:
Inside mount only (Side/Top Mount): Mount the beveled box installation brackets with
one screw through a side hole and one screw through the top hole, as shown below left.
Inside mount only (Side Mount): Mount the beveled box installation brackets with two
screws through diagonal side holes.
Inside or ceiling mount (Top Mount): Top mount the beveled box installation brackets
with screws through the two top holes, as shown below right.
Ceiling mount only: If the beveled box installation brackets are flush with the back wall,
attach them with one screw through a top hole and one screw through a rear hole.
Use a
3
⁄
32
" drill bit to drill holes for the mounting screws.
Attach the beveled box installation brackets using the screws provided.
IMPORTANT: The front edges of the beveled box installation brackets must align.
Beveled
Support
Bracket
Shim
Side/Top
Mount
Top Mount
To Next Page
